Shenzhen Wonder Printing System Co., Ltd WONDER,a professional manufacturer of corrugated digital printing system
7 Years
| Ask Lasest Price | |
| Brand Name : | WONDERJET |
| Model Number : | WD250-8A+ |
| Certification : | CE |
| Price : | Negotiable |
| Payment Terms : | T/T |
| Supply Ability : | 50 SETS/M |
| Delivery Time : | 1 M |
Auto Feeder Paper Box Printing Machine , Digital Color Printing Machine
Paper Box Printing Machine Description:
1. The Printhead temperature system, can effectively overcome the various low temperature environment.
2. Using stronger servo motor with high precision reducer, higher precision, faster speed, more stable performance.
3. Use 6 grade super high precision gear and high precision cylindrical grinding power roller, drive more accurately.
4. Strong rail beam, Mute guide rail,Printing flat error less than 0.2mm, makes the print more stable and higher accuracy.
5. New printhead cleaning mode, automatic cleaning,saving ink, printing more frequency.
Paper Box Printing Machine Specifications:
| Article NO. | WD250-8A+ Paper Box Printing Machine |
| Printhead quantity | 8 pieces |
| Ink type | Special water base dye ink |
| Color model | Cyan,Magenta,Yellow,Black |
| Medium distance | 2mm-4mm |
| Printing resolution | ≥600*180 dpi |
| Printing efficiency | Max 520㎡/hour |
| Printing format | Below 2500mm*1350mm under auto feeding |
| Drying speed | Liner-board can be dry once print out |
| Working environment | 15ºC-32ºC Indoor,Humidity 20%-70% |
| Ink supply | Automatic ink supply |
| Feeding mode | Automatic feeding |
| Material thickness | 2mm-35mm(max can be ordered to 50mm,if between 1.2mm and 2mm may need manual feeding) |
| Operate system | Professional RIP system,professional printing system,Windows 7 system with 32 bit operating system or above |
| Power supply | About 8.5 KW power:AC380±10%,50-60HZ |
| Machine size | L*W*H:2981*4593*1612(mm) |
| Package size | L*W*H:4820*2200*2035(mm) |
| Weight | NW:3000KGS ; GW: 3200KGS |
| Article NO. | WD250-8A+ |
Paper Box Printing Machine Advantage:
Printing way: scanning inkjet
High quality digital inkjet printing machine for corrugated carton
Your best selection for small and personalized orders
Environmental,energy saving, high efficiency and stable operation
Water-based dye ink,Environmental, automatic cleaning system
| Reference Data Sheet of Wonder Printer | |||||||||
| Printing mode | Model | Material | Material size (mm) | Printing size (mm) | Solution | Printing speed | Printhead | Production efficiency | Remark |
| Muti -pass | WD250-8A | Y/W kraft liner board | 2500*1350 | 2500*1350 | ≧180*360dpi | max 440㎡/H | EPSON | 100-350(PCS/H) | |
| WD250-16A | Y/W kraft liner board | 2500*1350 | 2500*1350 | ≧180*360dpi | max 780㎡/H | EPSON | 200-700(PCS/H) | ||
| WDR250-8A | Y/W kraft liner board | 2500*1350 | 2500*1350 | ≧300*360dpi | max 460㎡/H | RICOH | 120-450(PCS/H) | ||
| WDR250-16A | Y/W kraft liner board | 2500*1350 | 2500*1350 | ≧300*360dpi | max 820㎡/H | RICOH | 240-900(PCS/H) | With drying system can change inks to print on semi coated board | |
| WDUV250-12A | Y/W kraft liner board | 2500*1350 | 2500*1350 | ≧360*600dpi | max 230㎡/H | RICOH | 80-250(PCS/H) | ||
| WDUV250-24A | Y/W kraft liner board | 2500*1350 | 2500*1350 | ≧360*600dpi | max 460㎡/H | RICOH | 120-450(PCS/H) | ||
| Single Pass | WD200-24A | Y/W kraft liner board | 1800*2400 | 592*2400 | 360*180dpi 360*360dpi 360*720dpi | max 0.9 m/s max 0.6 m/s max 0.3 m/s | EPSON | 1200-3600(PCS/H) | |
| WD200-32A | Y/W kraft liner board | 1800*2400 | 790*2400 | 360*180dpi 360*360dpi 360*720dpi | max 0.9 m/s max 0.6 m/s max 0.3 m/s | EPSON | 1200-3600(PCS/H) | ||
| WD200-48A | Y/W kraft liner board | 1800*2400 | 1185*2400 | 360*180dpi 360*360dpi 360*720dpi | max 0.9 m/s max 0.6 m/s max 0.3 m/s | EPSON | 1200-3600(PCS/H) | ||
| WD200-64A | Y/W kraft liner board | 2200*2400 | 1580*2400 | 360*180dpi 360*360dpi 360*720dpi | max 0.9 m/s max 0.6 m/s max 0.3 m/s | EPSON | 1200-3600(PCS/H) | ||
| WDR200-48A | Y/W kraft liner board | 1800*2400 | 638*2400 | 600*200dpi 600*300dpi 600*600dpi | max 2.2 m/s max 1.6 m/s max 0.8 m/s | RICOH | 3200-12000(PCS/H) | With drying system can change inks to print on semi coated board | |
| WDR200-64A | Y/W kraft liner board | 1800*2400 | 851*2400 | 600*200dpi 600*300dpi 600*600dpi | max 2.2 m/s max 1.6 m/s max 0.8 m/s | RICOH | 3200-12000(PCS/H) | With drying system can change inks to print on semi coated board | |
| WDR200-92A | Y/W kraft liner board | 1800*2400 | 1223*2400 | 600*200dpi 600*300dpi 600*600dpi | max 2.2 m/s max 1.6 m/s max 0.8 m/s | RICOH | 3200-12000(PCS/H) | With drying system can change inks to print on semi coated board | |
| WDR200-124A | Y/W kraft liner board | 2200*2400 | 1649*2400 | 600*200dpi 600*300dpi 600*600dpi | max 2.2 m/s max 1.6 m/s max 0.8 m/s | RICOH | 3200-12000(PCS/H) | With drying system can change inks to print on semi coated board | |
| Muti -pass | WDUV320-16A | Building materials | min 320*320/pcs max 500*600/pcs | min 320*320/pcs max 500*600/pcs | ≧360*600dpi | max 1500 pcs/H | RICOH | 1000-1500(PCS/H) | 6 pcs |
| Single Pass | WDUV060-24A | Building materials | 600*600 | 319*600 | ≧300*600dpi | max 1.5 m/s | RICOH | ||
| WDUV060-28A | Building materials | 600*600 | 372*600 | ≧300*600dpi | max 1.5 m/s | RICOH | |||
| WDUV060-32A | Building materials | 600*600 | 425*600 | ≧300*600dpi | max 1.5 m/s | RICOH | |||
| WDUV060-36A | Building materials | 600*600 | 478*600 | ≧300*600dpi | max 1.5 m/s | RICOH | |||
| Remark | 1,Above material size is under auto-feeding situation,the length is
no limit if by maual feeding with scaning machine; 2,Auto drying system,auto varnish coating machine and auto slotting machine is optional to marched digital printer; 3,There're special water-based ink,waterproof latex ink and UV curable ink etc. | ||||||||
